Page #77 background imageLoading...
Page #77 background image
B
70
Specifications
M601d-A3 M701d-A3 M801d-A3
Screen Size: 60” 70” 80”
Viewable Area: 60.04” 69.51” 80.01”
Dimensions w/ Stand:
w/o Stand:
53.64” x 33.56” x 10.40”
53.64” x 30.90” x 2.22”
61.96” x 37.98” x 11.30”
61.96” x 35.69” x 2.32”
71.21” x 43.43” x 12.80”
71.21” x 41.10” x 2.62”
Weight w/ Stand:
w/o Stand:
70.55 lbs
63.93 lbs
97.00 lbs
85.98 lbs
134.48 lbs
113.98 lbs
TV Type: LED LED LED
Refresh Rate: 240 Hz with Backlight Scanning 240 Hz with Backlight Scanning 240 Hz with Backlight Scanning
Maximum Resolution: 1920 x 1080 1920 x 1080 1920 x 1080
Pixel Pitch: .692 mm (H) x .692 mm (V) .802 mm (H) x .802 mm (V) .923 mm (H) x .923 mm (V)
Dynamic Contrast
Ratio:
10,000,000:1 10,000,000:1 10,000,000:1
Response Time: 4ms 4ms 4ms
Brightness 2D Mode:
Brightness 3D Mode:
350 nits
130 nits
350 nits
130 nits
350 nits
130 nits
Viewing Angle: 178° (H) / 178° (V) 178° (H) / 178° (V) 176° (H) / 176° (V)
HDMI Inputs: 4 4 4
Component Video
Inputs:
1 1 1
Composite Inputs: 1 (Shared with Component) 1 (Shared with Component) 1 (Shared with Component)
RF Antenna Input: 1 1 1
