VM Audio ENCORE ECW120 - Single Speaker Wiring - Series Connection

Series Connection
WARNING! Make sure the ampli er is turned off before
connecting the subwoofer to the ampli er
SINGLE SPEAKER WIRING
9
A
B
C
Ported Box
6
ECW100
ECW120
22 inches (A)
26 inches (A)
ENCLOSURE DIMENSIONS
13 inches (B)
15 inches (B)
10 inches (C)
12 inches (C)
Box Volume
1.16 cu. ft
2.0 cu. ft.
Wood Thickness = 0.75”
