VM Motori D754IE3 - Page 70

- 8 -
C145301000.fm
English
Technical information
GB
D700/750 E2-E3
Thermostatic valve (E)
Fuel filter (F)
Water pump
(M)
IDM-45300900400.tif
Injector (C)
Heat exchanger (A)
Extraction collector
(L)
Turbocharger (B)
Waste-gate valve
(D)
Exhaust manifold (S)
Starter motor
(R)
Water collector (T)
Transmission belt (N)
Alternating current generator (Q)
Oil filter (G)
Oil sump (H)
Injection pump (P)
D704/D754/D706/D756
