VM Motori D754IE3 - Page 71

- 9 -
C145301000.fm
English
Technical information
GB
D700/750 E2-E3
D753
IDM-45300900300.tif
Extraction
collector
(L)
Oil filter (G)
Heat exchanger (A)
Thermostatic valve (E)
Injector (C)
Turbocharger (B)
Waste-gate valve (D)
Fuel filter (F)
Water pump (M)
Transmission belt (N)
Exhaust manifold (S)
Water collector (T)
Oil sump (H)
Starter motor (R)
Injection pump (P)
Turbocharger (B)
Oil sump (H)
Oil filter (G)
Heat exchanger (A)
Alternating current gen-
erator
(Q)
Fuel filter (F)
Alternating current gen-
erator
(Q)
Injection pump (P)
Injector (C)
Water collector (T)
