VX1 User manual
ASSEMBLY
Step 1
Remove the e-scooter from the packaging and
check whether all parts of the scope of delivery
(page 4) are included. Now adjust the stand so that
the e-scooter stands on its own.
Step 2
Now insert the brake cable into the opening of the
brake lever before placing the steering head on
the handlebar.
Step 3
Now fold the handlebar upwards so that the
folding mechanism engages.
Step 4
Now connect the cable of the handlebar and the
cable of the steering head together and then place
the steering head on the handlebar.
Step 5
Now tighten the four screws supplied so that the
steering head and the handlebar are fixed. Your
device is now completely assembled.
Folding
To fold the e-scooter back together, lift the red
safety catch and pull the folding lever. The handle-
bar can now be moved backwards/downwards.
Now engage the hook in the fixing piece for the
hook.
15
