Stasys
Page 3
Reference Manual
Features
Close tolerance and durable components provide increased reliability and greater output.
2 way - 3 way Active mode switch.
Unique 'waveformer' loading system ensures flat and even dispersion when arraying.
Accurately machined 15 laminate birch plywood cabinets for superior strength and longevity.
Built in Electronic Protection devices for both HF and MF drivers.
4 Aero Track Flying points for fast and accurate installation.
8 balanced grab handles for easier mobility.
Tough kick proof grills with foam filters protect the components from the heaviest of abuse.
Three year warranty and guarantee.
System Connections
In 2 way active mode Stasys 3 use's the 4 pole speakons. Pins +1 and -1 are connected to the LF
section and pins +2 and -2 are connected to the MHF section. An internal 3.2 KHz 2 way passive
crossover is used between the MF and HF sections when Stasys 3 is used in 2 way passive mode.
The suggested crossover frequency in 2 way active mode is 800 Hz between the LF and the MHF
sections.
In 3 way active mode the Stasys 3 use's the 8 pole speakons. Pins +1 and -1 are connected to the LF
section, pins +2 and -2 are connected to the MF section and pins +3 and -3 are connected to the HF
section. Pins +4 and -4 are not used. Programs are available for the Digidrive and Livedrive processors
which set the correct frequencies, filter type and slope for both 2 way and 3 way active modes.
The switch to change operating modes can be found on the rear connector panel.
Stasys 3's 4 pole speakon connectors are wired in parallel, the 8 pole speakons are also wired in
parallel, so either speakon can be used as the input. The other speakon can be used as a link output.
Do not connect to the 4 pole and 8 pole speakons at the same time
Please make sure the rear panel switch is set for the correct operating mode
Precautions
Please consider the following precautions during use :
1. Install the Stasys 3 enclosure in a dry environment, do not expose the cabinet to rain or moisture.
2. When flying or mounting the Stasys 3 ensure safe working practices and follow the recommended
rigging guidelines.
3. The Stasys 3 enclosure contains very powerful magnets. Do not locate an enclosure near any
sensitive equipment such as: VDU monitors, CRT TV's or high gain preamplifiers.
