Why is the output signal unstable on my Voith Transmitter?
If the output signal of your Voith Transmitter is unstable, first try increasing the damping until the signal stabilizes. If heavy vibrations in the pulp line are causing the signal drift, address the vibrations as soon as possible.
Why does the Voith Transmitter output signal vary with flow changes?
If the output signal of your Voith Transmitter changes with flow variations, first check if the transmitter is installed correctly according to the Installation Engineering Guide. Pay attention to the turbulence damping zone length after the pump and ensure the connection piece length is suitable for the consistency. If the installation is correct, the torque shaft might not be properly located, changing position with pressure fluctuations. In this case, the transmitter needs to be tested in a pressurized, water-filled test vessel. Contact BTG Service for further assistance. It is also possible that the position of the torque wheel changes somewhat when pressure changes, in this case contact BTG Service for assistance.
How to improve calibration precision on a Voith Transmitter?
If your Voith Transmitter calibration lacks precision, first ensure that Sample 1 (Feedback in water) is activated. Perform a new lab calibration. If it's hard to get good lab samples, perform a basic calibration using pre-defined constants. Select the pulp type and check the output from the transmitter, then adjust by inputting an offset.
How to fix low correlation factor in Voith Transmitter calibration?
If the calibration of your Voith Transmitter lacks precision due to a low correlation factor, start by checking the sampling equipment and the quality of sampling methods. Identify and deactivate any calibration samples that deviate significantly from the lab values. Perform a new calibration, ensuring the correlation factor exceeds 0.7. Also, check that Feedback in air value is within 10-20% (with sensor, propeller and mechanical seal mounted) and if not, contact BTG service assistance.
What to do if Voith Transmitter measurement has poor correlation to lab samples?
If the measurement from your Voith Transmitter has a poor correlation to lab samples, and consistency can vary, it is recommended that you add additional samples covering the entire calibration range. Then perform a new lab calibration.
Why is my Voith BTG MEK-3000 insensitive to consistency variations?
If your Voith Transmitter is insensitive to consistency variations, try changing the sensing element to a larger model. If the problem persists contact BTG Service for further assistance.
How to improve Voith BTG MEK-3000 Transmitter calibration precision outside normal range?
If the calibration of your Voith Transmitter lacks precision outside the normal working range, take additional calibration samples, ensuring they cover as much of the measuring range as possible.
How to fix cracked metal bellows on Voith BTG MEK-3000 Transmitter?
If the metal bellows of the mechanical seal on your Voith Transmitter are cracked, replace the mechanical seal. Contact BTG Service if this issue recurs quickly.
What to do if Voith BTG MEK-3000 Transmitter signal is unstable after sensor card change?
If the output signal of your Voith Transmitter is unstable after changing the sensor card, contact BTG Service for assistance.
How to resolve unstable signal level on Voith BTG MEK-3000 Transmitter?
If your Voith Transmitter shows an unstable signal level, contact BTG Service for assistance.
General| Brand | Voith |
|---|---|
| Model | BTG MEK-3000 |
| Category | Transmitter |
| Language | English |
Information on how to recycle the instrument and its parts according to regulations.
General safety instructions for operating BTG products and potential hazards.
Regulations that must be adhered to, superseding the document.
Identifies personnel who must familiarize themselves with the document's instructions.
Presumes necessary education and training for personnel working with BTG products.
Explains conventions used for DANGER, WARNING, and CAUTION admonitions.
Examples of danger signs found in manuals and on products.
General safety rules for installation and service procedures.
Overview of the MEK-3000 TwinTorque, its features, and technology.
Specifications for the MEK-3000, including general, function, process, ambient, and damping data.
Details on flushing water, power consumption, supply voltage, and cooling requirements.
Specific performance metrics like repeatability.
Information on mounting, materials, protection degree, and weight.
Detailed explanation of the information presented on the product's type plate.
Describes propeller types and rubber qualities for wetted parts.
Manufacturer's declaration of conformity with relevant CE directives.
Introduction to the CPM communication platform and its functions.
Technical specifications for the CPM communication platform.
Details on FCM and CCM modules, including network interfaces.
Specs on supply voltage, power, materials, temperatures, protection, and weight.
Diagrams and measurements for the CPM unit.
Explanation of markings on the CPM type plate.
Explains model designation, voltage, frequency, power, and factory ID.
Explains type specification codes and serial number.
EU Declaration of Conformity for the CPM.
FCC compliance information and statement.
Guidelines for choosing the optimal location for transmitter installation.
Requirements and recommendations for the dilution water supply system.
Minimum distance requirements for transmitter placement relative to pipe features.
Provides dimensional data and mounting recommendations for the MEK-3000.
Instructions and considerations for installing a weld-in saddle.
Installation details for measuring chambers with weld-in studs.
Information on measuring vessels for low-pressure installations.
Details on different sensing element types and their characteristics.
Recommendations for selecting propellers and hubs for MEK-3000 models.
Lists the contents of the MEK-3000 package.
Comprehensive guide for installing saddles, weld-in studs, and measuring vessels.
Detailed instructions for installing a weld-in stud for a 180 mm flange.
Instructions for installing measuring vessels with saddles.
Detailed instructions for installing a weld-in stud for a 270 mm flange.
Instructions for installing measuring vessels for 270 mm flanges.
General instructions for mounting the transmitter.
Procedure to check the movability of the mechanical seal.
Step-by-step guide for mounting the transmitter onto the pipe.
Instructions for attaching and removing the dirt cap.
Instructions for mounting optional accessories like inspection covers.
General instructions for making connections to the transmitter and CPM.
Details on connecting the flushing water supply.
Instructions for connecting an internal flow regulator for seal water.
Instructions for connecting an external flow regulator for seal water.
General instructions for electrical connections.
Specific instructions for connecting the communication platform.
Mounting instructions for the CPM, including recommended clearances.
Recommendations and notes regarding cabling.
Instructions for making internal connections within the CPM.
Steps for connecting the AC power supply to the CPM.
Instructions for making HART communication module (HCM) connections.
Instructions for making Fieldbus communication module (FCM) connections.
Details on the CCM-8200 module and its LEDs.
Information about using SD cards for backing up data.
Instructions for establishing an RS-485 connection.
Step-by-step guide for initial transmitter setup and operation.
Procedures for taking calibration samples for basic and lab calibration.
How to configure alarm and warning settings according to requirements.
Procedure for adjusting the transmitter's offset.
Importance of documenting settings and calibration data.
Recommendations for regular and long-term maintenance.
Details on weekly and semi-annual maintenance tasks.
General advice for cleaning and maintenance procedures.
Overview of service actions that can be performed on the transmitter.
Step-by-step guide for safely removing the transmitter from the pipe.
Instructions and parts for changing O-rings and sealings.
Guidance on replacing the electronics card.
Instructions for replacing sensing elements and propellers/hubs.
Instructions for changing the transmitter flange.
Procedure to read the Feedb value for specific serial numbers.
Step-by-step guide for removing the flange.
Instructions for removing mechanical and secondary sealings.
Step-by-step guide for mounting the flange.
Procedure for adjusting the angle setpoint for specific serial numbers.
Procedure for adjusting the angle setpoint for specific serial numbers.
Refers back to installation instructions for reinstallation.
Common symptoms, probable causes, and solutions for troubleshooting.
Defines connection blocks and calibration set configurations for HCM-8000.
Details data transfer between Profibus and transmitter for FCM-8000.
Lists available alarms and warnings for MEK-3000 and their configuration.
Lists available raw values and their descriptions from the CPM.
Details on life cycle diagnostics parameters for the MEK-3000.
Lists predefined calibrations available for different pulp types.
A form for documenting instrument settings and calibration data.
Introduction to the CPM communication platform and its operation.
Lists software versions for CPM modules and instruments.
Describes the CPM user interface elements like display and keys.
Explains how to interpret flow charts and instructions in the guide.
Details methods for inputting parameter values using the CPM interface.
Overview of the CPM menu structure and its sub-menus.
Explains the functions of the Measurement/Sample menu.
Describes how to navigate and use the Calibrate menu.
Explains how to navigate and use the Configure menu.
Explains how to navigate and use the Diagnostics menu.
Explains how to navigate and use the Backup menu.
Covers general operational aspects, including indicators.
Explains the various indicators shown on the CPM display.
Details how to manage and select calibration sets.
Explains the concept of channels for measurement results.
Procedure for checking and setting the CPM's date and time.
Focuses on viewing device status and instrument information.
How to view active alarms, warnings, and system status messages.
How to view live data and take samples from the instrument.
Accessing and modifying basic instrument settings.
Specific basic settings for the HCM-8000 module.
Specific basic settings for the FCM-8000 module.
Procedure for collecting and saving calibration samples.
Handling scenarios when the sample table is full.
Overview of the calibration menu functions.
How to view current calibration details.
Visual representation of sample value correlation to lab values.
Simplified calibration using predefined constants.
Calibration based on sample values and lab values.
Managing samples (activation, deletion, viewing info) for lab calibration.
Step-by-step procedure for performing lab calibration.
Overview of the configure menu options.
How to configure general instrument settings.
Configuring output settings for HART and Fieldbus modules.
Specific output configuration for HCM-8000.
Specific output configuration for FCM-8000.
Configuring sensor parameters like type, propeller, and torque.
Overview of the diagnostics menu.
How to view instrument life cycle diagnostic data.
How to configure instrument alarm functions.
How to configure instrument warning functions.
How to view logged events, alarms, and warnings.
Overview of backup and restore functions.
Procedure for storing instrument data on an SD card.
Procedure for restoring instrument data from an SD card.
Instructions for formatting memory cards for backup usage.
Storing instrument data and log tables onto a memory card.
Setting the logging update rate for data buffering.
Lists available spare parts and their part numbers.
Lists available accessories for the MEK-3000.
Details on different sensing element types, part numbers, and materials.
Lists available propellers and flanges with part numbers and characteristics.
Lists spare parts and kits for the CPM.
Lists accessories specifically for the CPM.
