Voith DSG-BXX113 - Page 5

Installation and Operating Manual
I/H Converter DSG-BXX113
2019 / 02
J.M. Voith SE & Co. KG │ Division Digital Ventures
Page: 5 / 20
918.3626018884 en
D – 74564 Crailsheim
Version: 3.3
Type
DSG- BXX 113
B05...
B07...
B10...
B30...
Output pressure
regulating range
P
A
[bar]
0..5 1..7 0..10 0..30
Input pressure
P
in
max [bar]
40 40 40 70
Flow rate line P → A
Q1
[l/min]
at ∆P = 1 bar
24 24 23 24
Flow rate line A → T
Q2 [l/min]
at ∆P = 1 bar
30 30 28 30
Regul. range approx.
P
A
max [bar]
at setpoint 20 mA
3..5 3,5..7 5..10 10..30
Regul. range approx.
P
A
min [bar]
at setpoint 4 mA
0..1,5
0..3
0,5..3
1..5
0..2
0..6
0..5
0..18
The regulating range of P
A
min depends on the set pressure P
A
max.
The regulating range of P
A
min indicated above refers to the minimum adjustable
pressure P
A
max.
Mechanical data:
Dimensions, fitting see chapter 10
Hydraulic connection see chapter 10
Type-depending installation position see chapter 10
Mounting position see chapter 10
Sealing material FPM
Weight approx. 12 kg
