It might be hard to determine exactly how much current is being
demanded through the BEC circuit . As a general guide , refer to
the chart below to determine approximately how many servos can
be used with the different size Easy-Plug ESCs. Remember, this
is only an approximation! More extreme setups ( with very high
powered digital servos, for example) will be more demanding on
the BEC circuit.
3 3 3
2 2 2
EP-10 ESC
BEC: 5V/1A
Micro or nano size
analog servos
Micro or nano size
high torque or
digital servos
Up to 8 NiCd/NiMH
cells, or 7.4V LiPos
9-10 NiCd/NiMH
cells, or 11.1V LiPos
12 NiCd/NiMH cells,
or 14.8V LiPos
6
EP-20 & EP-30 ESC
BEC: 5V/3A
Up to 8 NiCd/NiMH
cells, or 7.4V LiPos
9-10 NiCd/NiMH
cells, or 11.1V LiPos
12 NiCd/NiMH cells,
or 14.8V LiPos
Standard size
analog servos
Standard size
high torque or
digital servos
Micro or nano size
servos
6 6
4 4 4
6 6 6
EP-40 BEC: 5V/4A
EP-50& EP-60 ESC
BEC: 5.5V / 4A
Standard size
analog servos
Standard size
high torque or
digital servos
Up to 8 NiCd/NiMH
cells, or 7.4V LiPos
9-10 NiCd/NiMH
cells, or 11.1V LiPos
12 NiCd/NiMH cells,
or 14.8V LiPos
8 8 8
6 6 6
3
