❑ Always renew after removing
19 - Bolt
❑ M14 x 1.5 x 70
❑ 100 Nm + 90° further
❑ Do not tighten until pendulum support is bolted to gearbox
❑ Always renew after removing
20 - Bracket for skid plate
❑ Allocation ⇒ Electronic parts catalogue “ETKA”
21 - Bolt
Always observe size and strength class of the bolt. Different torque specifications apply.
❑ M10 x 75 strength class 8.8: 40 Nm and turn 90° further
❑ M10 x 75 strength class 10.9: 50 Nm and turn 90° further
Caution
From model year 08,
HeliCoil inserts are in‐
stalled in the pendulum
support connection in
the 02Q gearboxes.
Identification ⇒ Rep. Gr.
34
Use a bolt with hardness
class 10.9 for this and all
other gearboxes.
If there is no HeliCoil in‐
sert in the 02Q gearbox,
use bolts with the
strength class 8.8 and
the corresponding tor‐
que setting.
❑ Always renew after removing
22 - Bolt
Always observe strength class of the bolt. Different torque specifications apply.
❑ M10 x 35 strength class 8.8: 40 Nm and turn 90° further
❑ M10 x 35 strength class 10.9: 50 Nm and turn 90° further
Golf 2004 ➤ , Golf Plus 2005 ➤
Running gear, axles, steering - Edition 08.2009
12 Rep. Gr.40 - Front suspension
