01-112

Switch to measuring range:

Voltage measurement (20 V =)

Test

step

V.A.G

1598

sockets

Item tested

Test

conditions

- Additional

operations

Specification

Measures for

deviations from

specification

1 8 + 25 Voltage supply

for ABS hydraulic

pump -V64- to

ABS Control

Module (w/EDL) -

J104-

Ignition

switched

off

10.0 to 14.5

Electrical Wiring

Diagrams,

Troubleshooting &

Component Locations

binder

- Check wire using

wiring diagram

2 9 + 24 Voltage supply

for the valves in

ABS hydraulic

unit -N55- to ABS

Control Module

(w/EDL) -J104-

Ignition

switched

off

10.0 to 14.5

Electrical Wiring

Diagrams,

Troubleshooting &

Component Locations

binder

- Check wire using

wiring diagram

Ст

. 11 из 31ABS, ABS/EDL and ABS/EDL/ASR ITT Mark 20 IE, electrical chec
