01-170
Diagnostic Trouble Code (DTC)
memory, checking
Note:
All functions which could previously be
performed with V.A.G 1551 can now also
be carried out with the tester VAS 5051.
Rapid data transfer HELP
Select function XX
Indicated on display:
- Press keys -0- and -2-; 02 enters the
"Check DTC memory" function.
Rapid data transfer Q
02 - Check DTC memor
nized!
The number of stored DTCs or "No DTC
recognized" appears in the display.
-
Press key.
The stored DTCs are displayed and
printed out one after the other.
- With DTC information print-out, eliminate
malfunction according to DTC table,
Page 01-189 .
As with "No DTC recognized", the
program returns to the start position after
pressing the key:
Ст
