VOLTA FBW 721 - FBW (Flat Butt Welding System Model II) Layout

Figure 3: FBW Welder and Temperature Controller - Shinko
Figure 4: FBW Pliers
1
2
3
4
5
1
2
3
4
5
7
6
8
2.1. FBW Layout
1 Welder
2 Isolation Pad
3 Control Box (Shinko)
4 Temperature Control
5 Main Switch
6 Main Power
7 Output
8 Welder Input Plug
1 Crossbar
2 Locator Bar
3 Knob
4 Adjustable Lever
5 Operating Handle
6
Volta Belting Technology Ltd.
Welding & Fabrication Tools FBW-Flat Butt Welding System Model II
