INSTALLATION
This fan is designed for indoor spaces. Though not waterproof, it can be installed in alfresco settings and
coastal regions, as long as it is installed in an area safe from water, wind and dust, with at least one wall
on the side. If exposed to these elements, the warranty will be voided. Mounting the fan in a situation
where it is subject to water or moisture poses a safety risk.
Securely attach the hanger bracket to the ceiling using mounting screws.
Hanger
Bracket
Ceiling joist
NOTE: The ceiling fan must be installed 300mm minimum from the tip
of the blade to nearest object or wall.
The screws provided are for use with wooden supports only, if the
support is not wooden, appropriate screws must be used.
Connect 240V mains power to the terminal Block located on the hanger
bracket.
1
2
