Voltex CFWL - Page 9

INSTALLATION INSTRUCTIONS
9
Attach fan blades to motor using blade screws provided.
Carefully lift the fan and place the down rod with hanger ball assembly onto
the hanger bracket. Ensure that the groove in the ball is correctly aligned
with the tab on the hanger bracket.
Groove
Tab
Hanger
Bracket
Safety
Chain
Ceiling joist
3
4
