Volvo 2001 V70 - Engine Specifications

2001 VOLVO V70
http://new.volvocars.com/ownersdocs/2001/2001_V70/01v70_09.htm[4/4/2013 10:39:07 PM]
Gross vehicle weight (GVW)
V70 4630 lbs 2100 kg
V70 Turbo man. 4650 lbs 2110 kg
V70 Turbo aut. 4690 lbs 2130 kg
V70 AWD 4850 lbs 2200 kg
V70 XC 4890 lbs 2220 kg
Capacity weight ** 930 lbs 420 kg
Curb weight
V70 3315-3585 lbs 1505-1630 kg
V70 AWD 3665-3700 lbs 1665-1680 kg
V70 XC 3725-3760 lbs 1690-1710 kg
Permissible axle weight, front
V70 2290 lbs 1040 kg
V70 Turbo man. 2290 lbs 1040 kg
V70 Turbo aut. 2330 lbs 1060 kg
V70 AWD 2400 lbs 1090 kg
V70 XC 2490 lbs 1130 kg
Permissible axle weight, rear
V70, V70 Turbo 2470 lbs 1120 kg
V70 AWD 2580 lbs 1170 kg
V70 XC 2620 lbs 1190 kg
All specifications are subject to change without prior notice.
** The max permissible axle loads or the gross vehicle weight must not be exceeded.
pg. 138 Engine/transmission specifications
Engine specifications
Designation: Volvo B 5234 T3
Output 247 hp at 5200 rpm (184 kW/87 rps)
Max. torque 243 ft. lbs. at 2400-5200 rpm (330 Nm/42-87 rps)
Number of cylinders 5
Bore 3.19" (81 mm)
Stroke 3.54" (90 mm)
Displacement 2.3 liters
Compression ratio 8.5:1
Number of valves 20
Power transmission
Manual transmission: M 56 LK
Single-disc dry plate clutch. All-synchromesh on all gears including reverse; integrated final drive. Operation via a
floor mounted gear lever.
Final drive ratio 4.00:1
Reduction ratios
1st gear 3.39:1
