Volvo 2002 S80 - Climate Control System

2 0 0 2
VOLVO
S80
Chapter 3 - Climate control system
pg. 39 Climate control system
Ventilation 40
Electronic Climate Control (ECC) 41
Climate control system - general information 44
pg. 40 Ventilation
Air vents (dash)
A Open
B Closed
C Horizontal air flow
D Vertical air flow
Direct the outer air vents toward the side windows to demist.
In cold weather, close the air vents in the center of the dash to direct as much air as possible toward the windows.
