6 Power passenger's seat 30A
7 Heated front seat - left 15A
8 Heated front seat - right 15A
9 ABS 5A
10 -
11 -
12 Headlight wipers 15A
13 Electric socket 12 V 20A
14 Power passenger's seat, seat belt buckle switches, SRS 5A
15 Audio system 5A
16 Audio system 20A
17 Radio amplifier 30A
18 Front fog lights 15A
19 VNS display (option) 15A
20 -
21 Transmission module 10A
22 Direction indicators 20A
23 Headlight switch module, module for electrical connections, climate control system, onboard diagnostic
connector, steering wheel lever modules
5A
24 Relay for extended X-feed: climate control system, power driver's seat, text window, shiftlock
geartronic
10A
25 Ignition switch, Relay starter motor 10A
26 Control module - climate control blower 30A
27 Central locking system, power windows 15A
28 Power sun roof, courtesy lights, vanity mirror lights 10A
29 Telephone (option) 10A
30 Left front/rear parking lights 10A
31 Right front/rear parking lights, license plate lights 10A
32 Central electrical module, interior courtesy lights, power steering 10A
33 Fuel pump 15A
34 Power sun roof 15A
35 Defroster, Lighting, Sideview mirrors, central locking system, power windows - left front 25A
36 Defroster, Lighting, Sideview mirrors, central locking system, power windows - right front 25A
37 Power windows - rear doors 30A
38 Siren alarm 5A
pg. 115 Fuses in the cargo area
Fuses in the cargo area
The fuses in the cargo area are located on the trim on the left-hand side. When replacing a blown fuse, be sure to
replace it with a new one of the same color and amperage (written on the fuse).
