09 Maintenance and servicing
Wiper blades
09
216
Replacing windshield wiper blades
G020330
1. Fold out the wiper arm.
2. Press the button on the wiper blade attach-
ment and pull straight out (1), parallel with
the wiper arm.
3. Press a new wiper blade (2) until it clicks
into place.
4. Ensure the blade is securely attached (3).
5. Fold in the wiper arm.
The wiper blades are different lengths. The
blade on the driver's side is longer than the one
on the passenger's side.
G020329
Liftgate wiper blade
G007444
1. Fold out the wiper arm.
2. Remove the wiper blade by pulling it
straight out from the wiper arm.
3. Press the new wiper blade securely into
place.
Fold in the wiper arm.
Keeping the windshield/liftgate window and
wiper blades clean helps improve visibility and
prolongs the service life of the wiper blades.
See page 198 for washing instructions.
