09 Maintenance and servicing
Fuses
09
232
Fuse box in the engine compartment
G007446
The fuse box in the engine compartment has
positions for 36 fuses.
•
Fuses 1–18 are relays/circuit breakers and
should only be removed or replaced by an
authorized Volvo service technician.
•
Fuses 19–36 may be changed at any time
when necessary.
Several extra fuses and a fuse removal tool to
assist in removing/replacing fuses can be
found on the underside of the fuse box cover
in the engine compartment.
