08 Maintenance and service
Lamps
08
328
Direction indicators/flashers
G021750
1. Detach the headlamp.
2. Remove the small round cover.
3. Pull the bulb holder in order to extract the
bulb.
4. Remove the blown bulb and fit a new one.
It can only be installed in one way.
5. Fit the bulb holder in the socket and press
until a clicking sound is heard.
6. Refit the cover. It must be fitted and
pressed in until a clicking sound is heard.
Reinstall the parts in reverse order.
Side marker lamps
G021751
Before starting to replace a bulb, see
page 325.
1. Detach the headlamp.
2. Remove the small round cover.
3. Pull the cable in order to withdraw the bulb
holder.
4. Remove the blown bulb and fit a new one.
It can only be installed in one way.
5. Fit the bulb holder in the socket and press
until a clicking sound is heard.
6. Refit the cover. It must be fitted and
pressed in until a clicking sound is heard.
Reinstall the parts in reverse order.
Front fog lamps
G021753
1. Remove the cover by pressing in the 4 clips
with a thin blade and pulling straight out.
2. Unscrew the lamp housing screw and pull
it out.
3. Turn the bulb anticlockwise and remove it.
4. Fit a new bulb by turning clockwise.
5. Refit the bulb. (The profile of the bulb
holder corresponds to the profile of the
foot of the bulb).
6.
Refit the bulb holder. The TOP mark on the
bulb holder must always be upward.
