08 Maintenance and service
Lamps
08
329
Lamp housing, rear
G021754
The bulbs in the rear light cluster are replaced
from inside the cargo area (not the LED lamps).
1. Remove the covers in the left/right-hand
panel to access the bulbs. The bulbs are
located in separate bulb holders.
2. Press the catches together and pull out the
bulb holder.
3. Replace the bulb.
4. Plug in the connector.
5. Press the bulb holder into place and refit
the cover.
NOTE
If an error message remains after the broken
bulb has been replaced then we recom-
mend that you visit an authorised Volvo
workshop.
Location of rear bulbs
G021755
Lamp lens, right-hand side
Position/parking lights (LED)
Direction indicators
Side position lights (LED)
Brake light
Rear fog lamp (one side)
Reversing lamp
G015418
Rear lamp bulb holder
Direction indicators
Brake light
Rear fog lamp (one side)
Reversing lamp
