08 Maintenance and service
Lamps
08
330
Number plate lighting
G021756
1. Remove the screws with a screwdriver.
2. Carefully detach the whole lamp housing
and withdraw it.
3. Replace the bulb.
4. Refit the whole lamp housing and screw it
into place.
Lighting, cargo area
G021758
1. Insert a screwdriver and gently prize so
that the lamp housing comes loose.
2. Replace the bulb.
3. Check that the bulb illuminates and press
back the lamp housing.
Vanity mirror lighting
Removing the mirror glass
1. Insert a screwdriver in one of the two
recesses and carefully prize up the lug on
the edge.
2. Insert the screwdriver along the edge on
the left and right-hand sides and prize
carefully close to the black rubber sections
so that the mirror glass comes loose in the
lower edge.
3. Carefully detach and lift aside the entire
mirror glass and cover.
4. Replace the bulb.
Securing the mirror glass
1. Press the three lugs at top edge of the mir-
ror glass back into position.
