40
IMG- 214140
Applies to all models
Take two clips with tie straps for a Ø 8mm (5/16 ") hole from
the kit and press them into the two holes on the inside right of the
subframe.
41
IMG- 317748
Fold aside and attach the trailing edge of the wheel housing's
right fender liner for better access when installing the two
double -ties for the heater's cable.
