38
IMG-
317744
Insert the junction connector in the space in the sub-frame and
tighten down the junction connector around the rear cable with a
cable tie in the hole at the top of the sub-frame.
39
IMG-
300423
Applies to all vehicles
Take a cable tie with edge clips from the kit and press onto the
metal edge on the front right corner of the sub-frame, as shown.
Installation instructions, accessories
Volvo Car Corporation Gothenburg, Sweden
