Volvo Handsfree - Microphone Installation; Microphone Mounting Procedure

9
IMG -241301
Preparations
● Pull of the weatherstrip (1) for the door at the A- pillar.
● Pull off the A-pillar panel at the upper edge and then straight upwards to remove
it.
10
IMG -250288
Installing the microphone
● Tape a 700 mm length piece of foam tape on the microphone cable starting 90
mm from the microphone.
11
IMG -284125
Installing the microphone
● Clean the area on the microphone and headlining panel as illustrated, which
corresponds to the size of the double-sided adhesive tape. Use a solution of
25% isopropanol and 75% water, as well as a lint free cloth.
Dry with care, do not rub.
● Allow to dry.
● Remove the backing tape from one side of the Velcro strip and press it onto the
microphone.
Note!
In cases where the area is heavily soiled or treated with cockpit shine. First clean using
a washing up detergent (FAIRY or similar).
