TP397420 2 S40 (04-)/ V50 2004 131
64/12
12-pin gray
No. Dashboard harness Infotainment harness
163/12 Junction point
BK-BU
63/25G Junction point, Multimedia
Module (MMM)
16/60A:6 Phone Module (PHM)
BK-BU
16/93:1 Control module, cellular phone
handsfree, accessories
BN
24/56A:9 Central Electronic Module (CEM)
RD-YE
63/27 Junction point
RD-YE
363/29G Junction point
OG-YE
63/28 Junction point
OG-YE
16/93:2 Control module, cellular phone
handsfree, accessories
VT
16/93:5 Control module, cellular phone
handsfree, accessories
VT-WH
44/56A:8 Central Electronic Module (CEM)
RD-OG
16/60A:5 Phone Module (PHM)
RD-OG
54/56B:24 Central Electronic Module (CEM)
GY-OG
16/60A:12 Phone Module (PHM)
GY-OG
64/56B:25 Central Electronic Module (CEM)
BU-BK
16/60A:11 Phone Module (PHM)
BU-BK
716/1A:5 Infotainment Control Module
(ICM)
BK
7/182:3 Remote control IR sensor, RTI
BK
816/1A:6 Infotainment Control Module
(ICM)
GN-OG
7/182:2 Remote control IR sensor, RTI
GN-OG
9-
-
-
-
10 4/56A:33 Central Electronic Module (CEM)
GY-VT
16/60A:17 Phone Module (PHM)
GY-VT
11 -
-
-
-
12 -
-
-
-
64/18
2-pin white
No. Floor harness Tuner harness
116/16:1 Window antenna amplifier
BK
16/49A:1 Traffic Message Channel Module
(TMC)
BK
216/16:2 Window antenna amplifier
BK
16/94A:2 AM/FM Tuner Module (AFM)
BK
Connectors
64/12 - 64/18
