20-pin black
No. Floor harness Harness driver’s seat
8 4/9C1:23 Supplemental restraint
system module (SRS), LHD
4/9C1:75 Supplemental restraint
system module (SRS), RHD
GN-OG
8/51:2 Front left side airbag igniter
OG-BU
9 4/9C1:17 Supplemental restraint
system module (SRS)
OG
8/92:1 Lap belt tensioner, driver
-
10 4/9C1:18 Supplemental restraint
system module (SRS)
BN-GN
8/92:2 Lap belt tensioner, driver
-
11 73/5004 Branching point
VT-OG
4/52C2:3 Power Seat Module (PSM)
BU-RD
12 73/5003 Branching point
GY-OG
4/52C2:4 Power Seat Module (PSM)
GY-RD
13 31/7 Ground connection, LHD
73/5125 Branching point, LHD
BK-OG
8/51 Front left side airbag igniter
BK
31/84 Ground connection, RHD
73/5124 Branching point, RHD
BK-BU
14 73/5044 Branching point
VT-GN
4/52C2:1 Power Seat Module (PSM),
LHD
4/52C2:6 Power Seat Module (PSM),
RHD
RD-WH
15 11C/13:2 Fuse in distribution box
passenger compartment
GY-RD
4/52C1:1 Power Seat Module (PSM),
LHD
4/52C1:7 Power Seat Module (PSM),
RHD
RD
16 73/5035 Branching point, LHD
73/5023 Branching point, RHD
BK-VT
BK-GN
73/3 Branching point
BK
17 4/9C1:35 Supplemental restraint
system module (SRS)
BU
3/93:1 Contact, driver’s seat belt
buckle
-
18 4/9C1:36 Supplemental restraint
system module (SRS)
VT-BN
3/93:2 Contact, driver’s seat belt
buckle
-
19 -
-
-
-
20 -
-
-
-
Connectors
74/30:8-20
