Graphic Display 145
Brake
SID code
Description
1 ABS snsr axle 1 L
2 ABS snsr axle 1 R
3 ABS snsr axle 2 L
4 ABS snsr axle 2 R
5 ABS snsr axle 3 L
6 ABS snsr axle 3 R
7 ABS valve axle 1 L
8 ABS valve axle 1 R
9 ABS valve axle 2 L
10 ABS valve axle 2 R
11 ABS valve axle 3 L
12 ABS valve axle 3 R
13 ABS rtrdr ctrl relay
14 ABS relay, diagonal 1
15 ABS relay, diagonal 2
18 ABS, dif 1 - ASR valve
19 ABS, dif 2 - ASR valve
22 Speed signal input
23 Warning light bulb
24 ASR light bulb
FMI
code
Description
0 Data valid, but high
1 Data valid, but low
2 Data erratic
3 Voltage shorted high
4 Voltage shorted low
5 Current low or open C
6 Current high or short C
7 Mech syst no respons
8 Abnormal freq or PW
9 Abnormal update rate
10 Abnormal change rate
11 Failure unknown
12 Bad device
13 Out of calibration
14 Special instruction
1
1
This is displayed when the airbag has stored
crash data or by the data concentrator when the
engine shutdown output has been activated.
