308 Electrical System
Changing Headlight Bulb
The headlight bulb can be accessed from
the rear of the headlight assembly. Raise
the hood. Remove the clamps from the back
of the headlight box by lifting and pushing
them to the side. Remove the cover.
Remove the terminal from the back of the
bulb by bending up the lock tabs and
pulling back at the same time. Turn the
lock ring counterclockwise and remove.
Pull out the bulb.
W3002422
NOTE! When removing the new bulb from
the box, do not touch the glass with fingers
or anything that may put grease on the
glass surface.
Install the bulb and line up with the loca-
tion tab by turning it and then push it in
until fully seated. Install the lock ring. Push
the terminal back on. Check that the rubber
seal is clean and then install cover and snap
the clamps over it. Make sure to use the
correct replacement bulb.
W3002424
