Instruments and Controls 81
4 — No Charge Telltale
The No Charge telltale lights up red when
a problem exists in the charging system or
when there is no output from the alternator,
such as when the engine is not running.
The No Charge telltale lights up dimly
when there are several volts difference be-
tween the system voltage and the alternator
output voltage. The telltale shines brighter
as the alternator output voltage drops.
For more information on the electrical sys-
tem, see page 293.
T3008832
