General Information
Specifications
Read all Warnings Before Starting Installation!
An electric power transfer (EPT) provides a wiring path from the door to the frame.
These instructions assume that a factory-prepped door and frame are being used. If the door and frame have not
been factory-prepped, see the included dimensioned template.
Before beginning the installation, review “Specifications” and “Warnings”.
Applications
EPT can be used for:
• Door Thickness - 1-3/4” minimum
Note: The following specifications apply to a
1-3/4” thick door.
• 0 - 180° opening with up to 5” butt hinges
• 0 - 180° opening with up to 3/4” offset pivots
• 0 - 130° opening with 5-1/2” butt hinges
• 0 - 110° opening with 6” butt hinges
Electrical Ratings
EPT2
• Two 18AWG wires
• Max. Rating: 24VDC, 5A or
120VAC NEC Class 3
EPT cannot be used for:
• 1-1/2” offset pivots
• larger than 6” butt hinges
• pocket pivots
• swing clear hinges
• center hung door
(center pivot)
• balanced door
EPT10 & EPT10C
• Ten 24AWG wires
• Max Rating: 24VDC, 1A
Do not exceed rated specifications (shown above).
EPT must be installed in accordance with these instructions by a qualified electrician.
Wiring must be in accordance with all local codes and regulations.
CAUTION
!
CAUTION
!
CAUTION
!
