Vonyx MEG040 User Manual

3
HOW TO USE
1. ON / OFF Button
2. Talk button
3. Volume
4. Battery compartment unlock: Press to unlock the
battery compartment.
5. Built in microphone
6. Play Music
7. Record
8. Handle: Handle for easy use. When not in use,
the handle can be folded.
9. External microphone input.
10. USB/SD control panel
OPERATIONAL INSTRUCTIONS
1. Installing the batteries: Press the battery unlock button to open the top cover.
Put 6 pcs size D-batteries properly (+/- terminals must match) into the battery
compartment and close the top cover and the latch.
2. Position the horn opening towards the audience, and speak through the
microphone. Bring the microphone close to your lips and speak normally.
3. Adjust the volume level to optimum without causing howling. Please note that
the closer the sound source is to the microphone the better the amplification
is.
4. Switch the alarm switch to the alarm position, it will generate a continuous
alarm.
5. If the megaphone is activated and the volume of the speaker is weak, the batteries might be empty.
Follow step 1 to replace the batteries.
BASIC TROUBLESHOOTING
 If the megaphone does not work, remove the batteries to check if the +/- terminals match correctly.
 If the terminal match correctly, place back the batteries and press them down into the battery
compartment firmly, make sure the batteries are in contact properly
TECHNICAL SPECIFICATION
Power max. : 40Watt
Range : outdoor up to 700-1000m
Battery : 6pcs Type D-Battery
Battery lifetime : permanent use up to 5 hours
Dimensions : Ø190mm, Length 330mm
Weight (without battery) : 1.3Kg
The specifications are typical. The actual values can slightly change from one unit to the other.
Specifications can be changed without prior notice.

Vonyx MEG040 Specifications

General

Material	Plastic
Output power	40 W
Suitable for	Outdoor
Maximum range	1000 m
Product color	Red, White
Volume control	Yes
Megaphone modes	Siren
Power source type	Battery

Weight and Dimensions

Length	310 mm
Weight	1300 g
Diameter	195 mm
