TECHNICAL SPECIFICATION / TECHNISCHE SPECIFICATIE / TECHNISCHE
DATEN / ESPECIFICACIONES TÉCNICAS / SPÉCIFICATIONS TECHNIQUES /
SPECYFIKACJA TECHNICZNA
Frequency response: 20 – 20.000Hz
THD: <0.05%
Input level: mic: 10mV, 10kohm
Input level: Phono: 15mV, 22kohm
Input level: Line: 300mV, 30kohm
Signal-to-noise ratio: >75dB
Output level: Master: 2V
Equalizer: High: +/- 12dB
Equalizer: Low: +/- 12dB
Power supply: 220-240VAC 50Hz (12V Adapter)
Dimensions (L x W x H) : 331 x 205 x 40mm
Weight (kg) : 2.00
The specifications are typical. The actual values can slightly change from one unit to the other. Specifications can be changed
without prior notice.
The products referred to in this manual conform to the European Community Directives to which they are subject:
• Low Voltage (LVD) 2014/35/EU
• Electromagnetic Compatibility (EMC) 2014/30/EU
• Restriction of Hazardous Substances (RoHS) 2011/65/EU
