TECHNICAL SPECIFICATION / TECHNISCHE SPECIFICATIE / TECHNISCHE
DATEN / ESPECIFICACIONES TÉCNICAS / SPÉCIFICATIONS TECHNIQUES /
SPECYFIKACJA TECHNICZNA
Frequency response: 20Hz – 20KHz
THD: <0.02%
Equalizer – low +/- 12dB
Equalizer – high +/- 12dB
Input level – mic: 3mV, 2.2kohm
Input level – phono: 3.2mV, 47kohm
Input level – line: 150mV, 47kohm
Output level – master: 1V
Output level – headphone: 300mW
Power supply: 220-240VAC 50/60Hz
Dimensions (L x W x H): 205 x 110 x 215mm
Weight: 1,60kg
The specifications are typical. The actual values can slightly change from one unit to the other. Specifications can be changed
without prior notice.
The products referred to in this manual conform to the European Community Directives to which they are subject:
• Low Voltage (LVD) 2014/35/EU
• Electromagnetic Compatibility (EMC) 2014/30/EU
• Radio Equipment Directive (RED) 2014/53/EU
• Restriction of Hazardous Substances (RoHS) 2011/65/EU
