▮ ETHERNET&USB
No Description
1VCC
2
USB DATA
‐
1)USB
2
USB

DATA

‐
3USBDATA+
4GND
No Description
1N/C(NotConnected)
2
N/C (Not Connected)
2)ETHERNET
36
2
N/C

(Not

Connected)
3RX‐ (ReceiveData‐)
4N/C(NotConnected)
5N/C(NotConnected
6RX+(ReceiveData+)
7TX‐ (TransmitData‐)
8TX+(TransmitData+)
