3.2.4 EXTERNALCONNECTOR
▮ SENSORIN/RS‐485
Theexternalsensorterminal,RS‐485,receivesthedatafromtheexternalsensoror
Equipment.Andthedatasuchasthemotiondetection,motionsensorandvideoloss
Istransmittedtotheexternalequipments.
RS‐485
No Description No Description
1RS485+13SENSORINPUT5
2RS485‐ 14 SENSORINPUT6
3ALARMOUTPUT1 15 SENSORINPUT7
4ALARMOUTPUT2 16 SENSORINPUT8
5ALARMOUTPUT3 17 SENSORINPUT9
34
6ALARMOUTPUT4 18 SENSORINPUT10
7GROUND19SENSORINPUT11
8GROUND20SENSORINPUT12
9SENSORINPUT121 SENSORINPUT13
10 SENSORINPUT2 22 SENSORINPUT14
11 SENSORINPUT3 23 SENSORINPUT15
12 SENSORINPUT4
24 SENSORINPUT16
NOTE
Usercansetvaluesinmenu
