7
English
Screw
Screw
ScrewScrew
1. Remove the 4 screws located in between the ribs of the inlet
grille at roughly 10, 2, 5 and 7 o’clock positions. Do Not remove
the 2 screws on the pivot arms.
2. Dust or wash Front Grille with a mild dishwashing soap. Do not
place grille in the dishwasher. The excessive heat can distort the
plastic.
3. To remove the blades:
A. Pull the blade straight out from the shaft.
B. Wipe the Blade with a damp cloth. If your circulator is used
in a greasy environment, such as a kitchen, mild soap or a
common household cleaner may be necessary. Do not use
solvents. Do not place blade in the dishwasher. The excessive
heat can distort the plastic.
C. To reattach, push the blade all the way on the shaft until it
bottoms out. Do not use a hammer as this could result in
bearing damage.
4. To reattach grille - position the Front Grille so the Vornado logo
in the center of the Front Grille is straight. Replace all screws.
CLEANING
GRILLE AND BLADE REMOVAL Screwdriver required
WARNING: To reduce the risk of electrical shock and injury to persons, unplug the circulator before removing grille and blade.
Use the brush attachment on your household
vacuum cleaner to vacuum any accumulated
dust off the Front Grille and Air Inlets.
