Step 6&7. (saddle & seat post)
Insert seat post (32) into frame's seat tube and move upward or downward until at
a propor position then use stem lock lever(21) to fix it .
Assembly saddle (23) on saddle top slider (30) , sliding saddle in forward or backward
until at a propor postioon then use lock lever (31) to fix it .
NOTE: Do not arise above safety line.
Step 8. (bottle cage)
Attach bottle cage(14) on handlebar bottle hold bracket then use 2 screw
(13) to fix bottle cage on the bracket by a 4mm allen key .
STEP 6
STEP 7
14
13
STEP 8
