9 8
Dot-Centering
Screw (Elevation)
Dot-Centering
Screw (Windage)
Note: Perfectly centering the red dot in the Micro3X is not required
for accuracy. Once the primary red dot sight has been sighted in
using its own adjustments, the adjustments done to the Micro3X
using the centering screws will not affect the point-of-impact.
MICRO3X MAGNIFIER ADJUSTMENTS
Center the Red Dot Image
The Micro3X Magnifier is easy to use and does not require
any special sight-in—just zero-in the red dot as normal and
add the Micro3X behind for additional 3x magnification.
The dot-centering screws can be used to help center the
red dot in the magnifier’s field of view. After the Micro3X
is mounted behind red dot sight, the dot may seem off-
centered while viewing through the Micro3X. This will not
affect the point-of-impact. If desired, the centering screws
can be used to move the dot up/down or left/right until the
dot is more centered. Do not force screws once resistance is
felt and the end-of-travel range has been reached.
