Parts List
1
W010/MR
Air head 60cc
2
W560
Head washers 8,5 x 15 x 8
3
W530/12
Head-nut high-set m8
4
W003
Spark plug ngk b10 eg
5
W631/01MR
Copper head gasket 42,2 x 62,4 x 0,1
5
W631/02MR
Copper head gasket 42,2 x 62,4 x 0,2
6
W620/MR
O-ring head viton
7
W020/1MRC
Cylinder 60cc complete
8
W470
Exhaust stud bolt m7 x 32
9
W610/1MRC02
Cylinder basis gasket 0,2
9
W610/1MRC03
Cylinder basis gasket 0,3
9
W610/1MRC04
Cylinder basis gasket 0,4
9
W610/1MRC05
Cylinder basis gasket 0,5
10
W461/1VLC
Cylinder stud bolt m8 x 142
11
W2050/MR
Inlet manifold phbg 18
11
W2050/BR
Inlet manifold phbn 14
12
W825/1MR
Carburettor clamp d.23-35mm
13
V.TCE6X16
Socket-head screw m6 x 16
14
W820/BR
Dellorto carburettor phbn 14ms
14
W820/MR
Dellorto carburettor phbg 18b
15
W981400
Connector
16
W540/RVA
Exhaust fix. High set nut
17
W565
Exhaust washer d.8 x 12 x 1,5
18
W750/1MR
Exhaust manifold mr/t 60cc
19
W670/MR
Exhaust gasket
20
WA063
Head control template mini rok
21
WA064
Carburettor gap control template
32A
W050/MRC
Complete crankcase 60cc with bearing
33
V.TCE6X40
Socket head screw m6 x 40
34
V.TCE6X45
Socket-head screw m6 x 45
35
W075/1
Crankcase dowel 10 x 10,5 x 6,5
36
W10267
Copper gasket d. 8 x 12 x 1
37
W800
Depression pipe fitting m8 hexagonal
38
W300/MR
Insert 6204 c4
39
W310
Oil seal fpj 20 x 35 x 7 double lip
40
W940/ROK
Starter 50589
41
W019
Cylindrical pin 6x18
42
W924
Roller case bk0808
43
W916/ROK
Starter driving gear 50589
44
W910/ROK
Starter driving gear cover
45
V.TCE6X20
Socket-head screw m6 x 20
46
W960/RKT
Transmission starter support
47
V.TCE6X30
Socket-head screw m6 x 30
48
V.TCE6X65
Socket head screw m6 x 65
49
W972/MR
O.r.4200 starter support
50
W970/MR
Starter support d.50
51
W975/MR
Starter support spacer
64
W240/MR01A
Complete piston 41,88
64
W240/MR03A
Complete piston 41,91
64
W240/MR06A
Complete piston 41,93
64
W240/MR09A
Complete piston 41,95
64
W240/MR11A
Complete piston 41,98
64B
W260/MR95L
Piston ring 41,95
64B
W260/MR00L
Piston ring 42,00
64B
W260/MR05l
Piston ring 42,05
65
W280/MR
Circlip d.12,00
66
W270/MRA
Piston pin mini rok
67
W140/MR
Magn.s.h. Crankshaft 60cc
68
W122
Ignition key 2,5 x 3,7 x 10
69
W220
Silver-plated cage d.18 x 24 x 15
70
W290/MR
Piston cage 12 x 16 x 15,5
71
W200/1MR
Crankshaft crankpin d.18 x 40,6
72
W230/MR
Conrod engine 60cc
73
W522/10
Flathead screw m5 x 10
74
W160/MR
Nylon crankshaft stuffer
75
W121
Dragging sprocket key 3 x 3,7 x 10
76
W150/MR
H.crankshaft sprocket side 60cc
77B
W190/MR
Complete conrod 60cc
78C
W130/1MR
Complete crankshaft mini rok
79
W510/14
Socket-head screw m6 x 14
80
W1753/MR
Starting driven gear z 62
81
W1766/1ROK
Cylindrical pin 6 x 10
82
W1751/1KFC
Clutch rotor kf with pin
83
W1708
Belleville washer d.16,3 x 31,5 x 1,5
84
W1727
Clutch body fix nut m16 x 1 thr.
85
W1726/1
Washer 2,0 mm mini-kf
86
W523/08
Flathead screw m5 x 8
87
W1773/MR2
Bare clutch housing mini
