13
FOR USERS
3. TECHNICAL SPECIFICATION
Model
VPROPLUS
11
VPROPLUS
14
VPROPLUS
18
VPROPLUS
21
VPROPLUS
26
VPROPLUS
32
VPROPLUS
40T
Advised pool volume (m
3
) 25~40 30~50 40~65 45~75 55~90 65~105 75~120
Working air temp (°C / °F) -20 ~43 / -4 ~109
Performance Condition:Air 26°C / 80°F, Water 26°C / 80°F, Humidity 80%
Heating capacity (kW) in Turbo mode 11 13.5 18 21.5 26 31.5 40
Heating capacity (kW) in Smart mode 8.5 11.5 15 17.6 22 27 35
COP 20~7.3 19.6~7.5 19.2~7.1 20.5~7.2 20.3~7.2 19.6~7.4 19.8~7.2
COP at 50%capacity 14.7 14.9 14.6 15 15 14.8 14.7
COP at 20%capacity 20 19.6 19.2 20.5 20.3 19.6 19.8
Performance Condition:Air 15°C / 59°F, Water 26°C / 80°F, Humidity 70%
Heating capacity (kW) in Turbo mode 7.3 9 12 14.5 18 22 28.5
Heating capacity (kW) in Smart mode 6.1 7.3 10 12 14.8 18 24
COP 8.5~5.5 7.9~5.2 8.0~5.0 8.8~5.2 9.3~5.3 8.1~5.3 8.0~4.9
COP at 50%capacity 7.3 7.2 7.2 7.4 7.8 7.4 7.4
COP at 20%capacity 8.5 7.9 8 8.8 9.3 8.1 8
Performance Condition:Air 7°C / 45 °F, Water 26°C / 80°F, Humidity 90%
Heating capacity (kW) in Turbo mode 6.5 7.2 10.3 11.6 15.2 17.5 22.3
COP 7.0~4.8 6.9~4.5 6.9~4.3 7.2~4.4 7.1~4.6 7.1~4.6 7.0~4.3
Performance Condition:Air 35°C / 95°F, Water 28°C / 82°F, Humidity 80%
Cooling capacity (kW) 5 6.3 10 11.3 13 15 19.5
Sound pressure at 1m dB(A) 37.7~44.8 37.8~45.9 41.5~47.3 41.9~49.5 39.7~49.8 42.1~50.3 41.5~50.5
Sound pressure of 50%capacity at
1m dB(A)
38.8 40.3 42.5 43.3 43.1 45.2 42.5
Sound pressure at 10m dB(A) 17.7~24.8 17.8~25.9 21.5~27.3 21.9~29.5 19.7~29.8 22.1~30.3 21.5~30.5
Power supply 230V /1 Ph / 50Hz
400V/3
Ph/50Hz
Rated input power (kW) at air 15°C /
59°F
0.15~1.38 0.19~1.7 0.25~2.45 0.27~2.74 0.32~3.31 0.46~4.1 0.60~5.7
Rated input current (A) at air 15°C /
59°F
0.65~6.00 0.83~7.39 1.09~10.65 1.17~11.9 1.39~14.4 2.01~17.8 0.87~8.22
Advised water ux (m³/h) 2~4 3~4 4~6 6.5~8.5 8~10 10~12 12~18
Water pipe in-out Spec (mm) 48.3
Net Dimension L × W × H (mm)
910×432×
660
945×432×
660
1045×432×
660
1195×432×
760
1072×536×
956
1074×536×
956
1260×536×
956
Net Weight (kg) 63 65 73 82 100 122 147
The values indicated are valid under ideal conditions: Pool covered with an isothermal cover, ltration system
running at least 15 hours a day.
Related parameters subject to adjustment periodically for technical improvement without further notice. For
details please refer to nameplate.
