6 7
Windage Adjustment
Elevation Adjustment
Windage and Elevation Adjustments
Use a coin or other flat head item to turn the knobs to adjust for
point of aim. For both adjustment knobs, one click will change
the point of aim approximately ½ MOA when zeroing.
One full rotation of either knob will change the point of aim
approximately 16.5 MOA—8.25” at 50 yards or 16.5” at 100
yards when zeroing.
Please note:
When adjusting, you may encounter increased resistance. This
means the end of the adjustment range has been reached
and you should not turn the knob any further.
One click yields ½ MOA of adjustments
¹/8-inch (3.18mm) at 25-yds (23.75 meters)
¼-inch (6.35mm) at 50-yds (47.5 meters)
