Vortex VO4229 - Assembly Procedure

Tower Fan VO4229
2
a-Control panel b.-Handle (behind unit) c-.Air inlet d.-Stand e.-Air outlet
f- Display j- REMOTE CONTROL
Assembly:
Take the fan out of the package and check the device as well as the scope of de- livery menoned above.
Please contact the vendor if any part is missing or has been damaged.
First assemble the pedestal. Then mount the pedestal to the fan. Make sure that you route the cable
through the strain-relief, ghten it and do not damage the cable in the process.
Then x the pedestal to the fan using the mounng screws
.
