Assembly instructions VOSS quick connect system 246
NX
, page 2 of 18
A. Important notices
before using the quick connect system
VOSS quick connect system 246
is suitable for the following fluids:
diesel, biodiesel, coolant, and AdBlue
®
/DEF. Different applications may require
different O-ring materials.
Temperature range from -40 °C to +120 °C, temporary +140 °C
Maximum operating pressure 10 bar, depending on applied tube materials and
dimensions
When using the quick connect system in other applications, suggestions available
upon request.
during the assembly of the quick connect system
The assembly of the quick connect system must be conducted by professional
mechanics subject to these assembly instructions.
Incorrectly assembled connections can result in fluid leakage and failure of the system.
VOSS quick connect system 246
may only be used with ports and tubes made of
materials described in chapter B (components and materials).
Do not connect nylon tube and fir-tree with hose clips or clamping sleeves.
The O-ring must be greased.
Do not remove the connecting cap until ready for assembly.
VOSS quick connect system 246
permits rapid and safe connections of nylon tubes
to system components and between lines.
VOSS quick connect system 246
features a particularly space-saving construction,
making it useful in tight installation spaces.
The retaining element can be rotated. It can be aligned in 8 steps and thus be adapted
to the specific installation space situation for a comfortable disassembly.
Different fir-tree and respective tube dimensions can be distinguished by color markings
on the retaining element.
VOSS quick connect system 246
is also available as an electrically heated variant.
Please ask for a special assembly instruction if needed.
