Votronic Info Panel Pro - Connection Configuration Details; Terminal Connections and Cable Specs

- 7 -
Cable Cross-Sections
from a length of 2 m
1 mm
2
6 mm
2
6 mm
2
1 mm
2
1 mm
2
1 mm
2
1 mm
2
1 mm
2
2.5 mm
2
1 mm
2
up to a length of 2 m
1 mm
2
4 mm
2
4 mm
2
1 mm
2
1 mm
2
1 mm
2
1 mm
2
1 mm
2
2.5 mm
2
1 mm
2
Configuration of Connections Info Panel Pro
Female Connector
--
6.3 mm yellow
6.3 mm yellow
--
--
--
--
--
6.3 mm blue
--
Designation
Board Battery “-“ (Minus)/Body Ground
Board Battery "+" (Plus)
Output “+” Consumers of Board Battery
Starter Storage Battery "+" (Plus)
Tank Pulse Fresh Water
Tank Pulse Sewage Water
Tank Pulse Feces
Tank “+”, switched for Fresh Water, Sewage Water and Feces Tank
Pump "+" (Plus)
Battery Protector, see Page 3
No.
1
2
2a
3
4 Fri
4 Ab
4 Wc
5
6
8
