- 8th -
General information:
Troubleshooting:
If no connection to the smartphone / tablet can be established:
- Make sure that Bluetooth is activated on the phone / tablet.
- Make sure the Bluetooth Connector S-BC to connect to the solar controller and / or smart shunt, has by
watching the LEDs on the device. These must flash at least every 5 seconds, thus signaling the reception of
data.
- Check the operating voltage (battery) of solar controller and / or smart shunt.
Technical specifications
Nominal voltage (supplied from connected devices) 12 V / 24 V operating voltage
range 8 ... 32 V
Power consumption in standby, typically 0.3 mA
Current consumption with active app, typical 4 mA
Environmental conditions, Humidity Max. 95% RH, non-condensing
Dimensions 75 x 47 x 24 mm
Weight approx 37 g
Approvals CE
Scope of delivery:
Bluetooth Connector S-BC
manual
2 St. control line 6-pin 1 m long
Available accessories:
Control line extension 5 m long No. 2005
Declaration of Conformity:
In accordance with the provisions of Directives 2014/35 / EU 2014/30 / EU 2009/19 / EC this product complies with the
following standards or normative documents: EN55014-1; EN55022 B; EN61000-6-1; EN61000-4-2; EN61000-4-3;
EN61000-4-4; EN62368-1; EN50498.
The product
must not be
disposed of with
household
waste.
The product is RoHS compliant. It
conforms with the Directive 2011/65 / EC
on the restriction of hazardous
substances in electrical and electronic
equipment.
Made in Germany by VOTRONIC
Electronic Systems GmbH, Johann-Friedrich-Diehm-Str. 10, D-36341 Lauterbach All rights, especially the right of reproduction
reserved. copyright • VOTRONIC 10/2018. Subject to misprints, errors and technical changes.reserved. copyright • VOTRONIC 10/2018. Subject to misprints, errors and technical changes.reserved. copyright • VOTRONIC 10/2018. Subject to misprints, errors and technical changes.
Tel .: +49 (0) 6641 / 91173-0 Fax: +49 (0) 6641 / 91173-20 E-mail: info@votronic.de Internet: www.votronic.de
