KORG VT40+ Parts List
= SAFETY CRITICAL COMPONENT.
EXP=EXPLODED VIEW Item No
Part Number Category Part Name Location EXP Reference QTY
530000001086 CHIP INDUCTOR HH-1M2012-121 JACK FB1 1
530000001116 WAFER WAFER LWL0640 3P JACK CN1 1
530000001945 JACK BPJ-BNB-P, 8MM JACK J1 1
530000001116 WAFER WAFER LWL0640 3P FOOT SW CN4 1
530000001094 OP-AMP NJM072 (SMT) MAIN IC7 1
530000000194 OP-AMP IC NJU7082 MAIN IC5 1
530000002347 IC POWER IC TAS5615 MAIN IC8 1
500324018020 DAC AK4384ET-E2 MAIN IC4 1
500324018021 ADC AK5358AET-E2 MAIN IC11 1
500320004748 IC R5F21388AN101FP U1 MAIN IC3 1
500320012334 DSP MB87R1420PMC-G-BND MAIN IC14 1
530000000179 HEX INVERTER IC 74LVU04DB MAIN IC2 1
530000001098 REGULATOR UTC UR3325 MAIN IC9 1
530000002307 REGULATOR REGULATOR LM1117 5V MAIN IC6 1
530000002348 REGULATOR REGULATOR KIA78L12F MAIN IC13 1
530000001948 CHIP TR KTC3295 MAIN Q1 1
530000000279 CHIP TR TR KTC4075 MAIN Q2,Q3,Q4,Q18 4
530000000275 CHIP TR TR KTC2875 MAIN Q8 1
530000000277 TRANSISTOR TR KTC3198GR MAIN Q9,Q10 2
530000000150 DIODE D 1N4002 MAIN D25,D26 2
530000002349 ZENER DIODE ZENER DIODE 1N5252B (1/2 24V) MAIN D22 1
530000002350 ZENER DIODE ZENER DIODE 1N4739 (1W 9.1V) MAIN ZD2 1
530000002351 ZENER DIODE ZENER DIODE 2EZ6.2D5 (2W 6.2V) MAIN ZD3 1
530000001103 LED 3O4HD-7 MAIN LED11 1
530000000208 LED LED RED 3M/M DLL-B5131Q MAIN
LED4,LED5,LED6,LED7,
LED8,LED9,LED10,LED13
8
530000002196 LED DLL-B2131Q(G124) MAIN LED14 1
530000001102 LED 3RG9HW-2-A MAIN LED1,LED2,LED3 3
530000001225 LED SUPPORT LED SUPPORT SW 4010 - 10MM MAIN 9
530000001226 LED SUPPORT LED SUPPORT SW 4009 - 9MM MAIN 3
530000000804 BRIDGE DIODE BRIDGE DIODE KBU4K MAIN D7 1
530000001380 CHIP INDUCTOR HH-1M1608-600JT MAIN
FB4,FB5,FB6,FB7,FB8,
L1,L2,L17,L20,L21
10
530000002308 CHIP INDUCTOR CHIP INDUCTOR HH-1M1608-121 MAIN FB3 1
530000000802 BEAD CORE BEAD CORE FBS3550A0 .T MAIN FB2 1
530000002352 INDUCTOR RING COIL INDUCTOR 15UH 3A MAIN L3,L4,L5,L6 4
530000002309 CRYSTAL CRYSTAL 20MHZ MAIN X1 1
530000002353 RESISTOR CARBON RESISTOR 1/2W 33 OHM MAIN R70,R112 2
530000002354 RESISTOR CARBON RESISTOR 1/2W 56 OHM MAIN R280 1
530000002355 RESISTOR METAL OXIDE RESISTOR 1W 10 OHM MAIN R159 1
530000002356 RESISTOR CARBON RESISTOR 2W 120 OHM MAIN R46 1
530000002357 RESISTOR CARBON RESISTOR 3W 33 OHM MAIN R62 1
530000002358 RESISTOR WIRE WOUMD 5W 0.1 OHM MAIN R141 1
530000002317 RESISTOR CEMENT RESISTOR 5W J 47 MAIN R205 1
530000002318 VOLUME SEMI VOLUME KVSF689AC103 (10K) MAIN VR14 1
530000000288 VOLUME VR RV160-40-15S-B10K-C0 MAIN
VR1,VR4,VR5,VR6,VR7,
VR9,VR11,VR12,VR13
9
530000002319 VOLUME VOLUME VR RV160-40-15S-B1K-C0) MAIN VR2 1
530000000289 VOLUME VR RV160-40-15S-B10K-C11 (11C) MAIN VR3,VR8,VR10 3
To Next Page
