EN -8
3. TECHNICAL SPECIFICATIONS
3.2. Technical specifications
Capacity
10place
settings
Dimensions
(mm)
Height
Width
Depth
820-870(mm)
450(mm)
550(mm)
Net weight 32 kg
Operating
voltage /
frequency
220-240V
50 Hz,
Total current
(A)
10(A)
Total power
(W)
1900(W)
Water supply
pressure
Maximum:
1 (Mpa)
Minimum:
0.03 (Mpa)
12
3.1. General appearance
1. Upper basket with racks
2. Upper spray arm
3. Lower basket
4. Lower spray arm
5. Filters
6. Rating plate
7. Control panel
8. Detergent and rinse-aid dispenser
9. Cutlery basket
10. Salt dispenser
11. Upper basket track latch
12. Mini Active Drying Unit: This system
enhances the drying performance of
your dishes.
