Vox AC10C1 Service Manual

Code Part Name Location EXP Reference QTY
530000003395 TRANS AUDIO 173.2/12.6V 10W0.06A 20 1
530000003396 SCREW M4X12 PH BK 30 6
530000003397 TRANS PWR 240/250-12.6V/AUS 31
530000003398 TRANS PWR 230/250-12.6V/EU/UK/ARG 31
530000003399 TRANS PWR 120/250-12.6V/US/120V 31
530000003400 TRANS PWR 100/250-12.6V/JP 31
530000001921 FUSE T630MA 250V EU/UK/AUS 32 1
530000001920 FUSE T1.25A 250V JP/US 32 1
530000002611 AC INLET M 3P 250V 10A(NT50H) 33 1
530000003401 LENS PC SHEET 80X40 PC BK/EU/UK /ARG 39 1
530000002080 VALVE COMPACTRON 12AX7B 41 2
530000003184 SWITCH POWER TOGGLE SPDT 43
(
* for 230V onl
y)
530000002641 SWITCH POWER SPST 250V 43
530000003370 LED HOLDER D9.25X13.4 ME 44 1
530000002923 KNOB-CHICKENHEAD AC4C1 45 5
1
1

Vox AC10C1 Specifications

General

Power Output	10 Watts
Speaker	1 x 10" Celestion VX10
Preamp Tubes	2 x 12AX7
Power Tubes	2 x EL84
Channels	1
Inputs	1 x 1/4"
Footswitch I/O	No
Type	Tube
Controls	Reverb
Outputs	1 x 1/4" (External Speaker)
Dimensions	20.47 x 8.27 x 16.14 inches
Weight	27.12 lbs
